Case TypeMini / Micro Tower
Form Factor (Motherboard Support)Micro-ATXmini-ITX / micro-ATX
CPU Cooler Maximum Height156–165 mm
165 mm
GPU Maximum Length361 – 400 mm400 mm (270 if liquid cooling is installed on the inner panel)
max. Radiator Support360 mmBack panel: 120 / Inner panel (next to motherboard): 120/240/360/280 (maximum height 52 mm) / Top panel: 120/240/360/280 (maximum height 52 mm)
Radiator Support დამ.ინფო-
Preinstalled Fans4+ fans4 pcs(Internal panel (next to motherboard): 3x 120 ARGB (PWM), Rear panel: 1x 120mm ARGB (4pin PWM))
Fan Support (Maximum)7+ fans7 pcs(Inner panel (next to motherboard): 3x 120, Top panel: 3x 120/140, Rear panel: 1x 120)
ფერისხვა
PCI Expansion Slots7
Drive Bays2 Internal panel (rear side of motherboard tray): 1x 3.5" or 2x 2.5" / additionally on the side of the power supply housing 1x 2.5"
I/O Ports 1xUSB Type C
დამატებითი ინფორმაცია-
ქეისის ზომები 220 x 440 x 455
