Case TypeMini / Micro Tower
Form Factor (Motherboard Support)Mini-ITX6.7” x 6.7” (Mini ITX)
CPU Cooler Maximum Height176 mm+190mm
GPU Maximum Length331 – 360 mm330mm
max. Radiator Support120 mm
Radiator Support დამ.ინფოTop: 1 x 120mm
Preinstalled Fans2 fansTop(exhaust):
120 x 120 x 25 mm Standard fan (1500rpm, 35.8 dBA) x 1
Rear(exhaust):
120 x 120 x 25 mm Standard fan (1500rpm, 35.8 dBA) x 1
Fan Support (Maximum)3 fansTop:
1 x 120mm, 1 x 140mm
Rear:
1 x 120mm, 1 x 140mm
Top of the PSU Cover:
1 x 120mm, 1 x 140mm
ფერისხვა
PCI Expansion Slots2
Drive Bays2 x 2.5“(with side bracket); 2 x 2.5“ or 2 x 3.5” (without rear fan)
I/O PortsUSB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 2
დამატებითი ინფორმაციაTempered Glass x 3 (4mm thickness) | 6.1 kg
ქეისის ზომები462.8 x 266 x 266 mm
