Case TypeMid Tower
Form Factor (Motherboard Support)E-ATX6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13” (E-ATX)
CPU Cooler Maximum Height176 mm+190mm
GPU Maximum Length401 mm+327mm (With radiator)
410mm (Without radiator)
max. Radiator Support420 mm
Radiator Support დამ.ინფოFront: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm Rear: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm Bottom: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm
Preinstalled Fans3 fansFront(intake):
140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1
Top(exhaust):
140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1
Rear(intake):
140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1
Fan Support (Maximum)7+ fansFront:
3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
2 x 200mm, 1 x 200mm
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Right:
1 x 120mm, 1 x 140mm
Rear:
3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
Bottom:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
ფერისხვა
PCI Expansion Slots7
Drive Bays7 x 3.5” or 6 x 2.5”
I/O PortsUSB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1
დამატებითი ინფორმაცია4mm Tempered Glass x 2 | 15.6 kg
ქეისის ზომები566.5 x 327.6 x 505.5 mm
