🧱 Form FactorSFP+
⚡ Speed / Standard10G (10GBASE-SR / LR / ER)
📡 Fiber TypeMulti-Mode (MMF)
🔌 Connector TypeLC Duplex
🌈 Wavelength (nm)850 nm
📏Transfer DistanceUp to 300m
Max Power Consumption≤ 1 W (typical for 10G SR SFP+ class)
TX Power-6.5 to -1 dBm
RX Power-11.1 dBm sensitivity (typical SR receiver level)
Operation Voltage3.3V ± 5%
დამატებითი ინფორმაცია10GBASE-SR IEEE 802.3ae compliant
850nm VCSEL laser
Hot-swappable SFP+ module
LC duplex interface
Supports multimode fiber (50/125µm, 62.5/125µm)
Low power consumption design
Enterprise / data center optical link (EnGenius SFP+ series)
